DIN 371/376 HSS-PM Spiral Flute Tap - M3 to M24
DIN 371/376 HSS-PM Spiral Flute Tap - M3 to M24
DIN 371/376 HSS-PM Spiral Flute Tap
High-speed steel powder metallurgy (HSS-PM) spiral flute taps manufactured to DIN 371 and DIN 376 standards. Spiral flute geometry evacuates chips upward during threading operations.
Specifications:
- Material: HSS-PM (High-Speed Steel Powder Metallurgy)
- Standard: DIN 371 (Machine Taps), DIN 376 (Dimensions)
- Type: Spiral Flute
- Coating: TiCN (Titanium Carbonitride)
- Thread Standard: Metric ISO
- Shank Type: 6HX (Hexagonal)
Available Sizes:
M3, M4, M5, M6, M8, M10, M12, M14, M16, M18, M20, M22, M24
Size Chart:
| Size | Pitch | O.A. Length | Thread Length | Working Length | Shank Ø | Drill Ø |
|---|---|---|---|---|---|---|
| M3 | 0.5 | 56 | 10 | 18 | 3.15 | 2.5 |
| M4 | 0.7 | 63 | 12 | 20 | 4 | 3.3 |
| M5 | 0.8 | 70 | 14 | 22 | 5 | 4.2 |
| M6 | 1 | 80 | 16 | 26 | 6 | 5 |
| M8 | 1.25 | 90 | 18 | 30 | 6.3 | 6.8 |
| M10 | 1.5 | 100 | 20 | 34 | 8 | 8.5 |
| M12 | 1.75 | 110 | 22 | 38 | 10 | 10.2 |
| M14 | 2 | 125 | 24 | 42 | 11 | 12 |
| M16 | 2 | 140 | 28 | 48 | 12.5 | 14 |
| M18 | 2.5 | 140 | 30 | 50 | 14 | 15.5 |
| M20 | 2.5 | 160 | 32 | 54 | 16 | 17.5 |
| M22 | 2.5 | 160 | 34 | 58 | 18 | 19.5 |
| M24 | 3 | 180 | 36 | 62 | 20 | 21 |
Technical Notes:
- Spiral flute design evacuates chips upward, suitable for blind hole applications
- HSS-PM construction provides improved toughness and wear resistance compared to standard HSS
- TiCN coating reduces friction and extends tool life
- 6HX shank compatible with standard tap holders
- Conforms to DIN 371 and DIN 376 dimensional standards
Applications:
Suitable for threading operations in steel, stainless steel, cast iron, and non-ferrous metals. Recommended for blind hole threading where upward chip evacuation is required.
For Technical Information & Trouble Shooting click here
